Camera

Image Sensor
1/2.7"CMOS
Min. Illumination
Color:0.001lux@ (F1.6,AGC ON),B/W:0lux with IR
Shutter Time
1s~1/100000s
Day&Night
IR-cut filter with auto Switch (ICR)
Smart IR
Yes
WDR
120dB
S/N
39dB
Lens

Focal Length
4.7mm~141mm
Optical Zoom
30X
Digital Zoom
16X
Zoom Speed
<5s
Aperture Range
F1.6~F4.3
Aperture Type
Auto(P-Iris)
Field of View
61.9°~2.5°(H); 35.5°~1.4°(V); 69.1°~2.9°(D)
Focus Control
Auto/Semi-auto/Manual
Close Focus Distance
100mm~1500mm
DORI Distance
Detect:2600m Observe:1031m Recognize:520m Identify:260m
Pan&Tilt

Pan Range
360°
Pan Speed
Manual Speed:0.1°～180°/s Preset Speed:240°/s
Tilt Range
-16°~90° (Default -3°~90°)
Tilt Speed
Manual Speed:0.1°～120°/s Preset:120°/s
3D Position
Yes
Preset
500
Cruise
16,up to 32 presets per cruise
Scan
8
Pattern
8,each with 600s memory or 1000 orders
Scheduled Task
Preset,Cruise,Scan,Pattern
North Point
Yes(Manual setting)
Power-off Memory
Yes
Illuminator

IR LEDs
10
IR Distance
Up to 200m
Wavelength
850nm
IR Irradiation Angle
Yes
Compression Standard

Video Compression
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
Video Bit Rate
32Kbps~16Mbps
Audio Compression
G.711A/G.711U/ADPCM_D/AAC_LC
Audio Sampling Rate
8KHz/32KHz/48KHz

Max. Resolution
5MP,2880×1620@30fps
Main Stream
PAL:25fps(2880×1620,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720) NTSC:30fps(2880×1620,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720)
Sub Stream
PAL:25fps(704×576,704×288,640×360,352×288) NTSC:30fps(704×480,704×240,640×360,352×240)
Third Stream
PAL:25fps(1920×1080,1280×960,1280×720,704×576,640×480,704×288,352×288) NTSC:30fps(1920×1080,1280×960,1280×720,704×480,640×480,704×240,352×240)
BLC
Yes
HLC
Yes
AGC
Yes
3DNR
Yes
White Balance
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance
ROI
7 rectangular 3D fixed focus areas,supporting 1 rectangular dynamic tracking ROI
OSD
5 regions(Each region can have a maximum of 127 characters ,up to 5 lines); 16*16/24*24/32*32/48*48/64*64/96*96/adaptable size; Vector/Lattice
Defog
Yes
Flip
Normal/Horizontal Mirror/Vertical Mirror/Inverted Flip
Regional Exposure
Yes
Regional Focus
Yes
Demist
Yes
Privacy Mask
24 regions(Up to 4 blocks in the same scene)
Feature

General Alarm
Motion Detection; Mask Alarm; Alarm Input
Exceptions Alarm
Disk Full; Disk R/W Error; Recording Exception; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Network cable disconnected
Linkage Method
Send Email; Trigger Sound; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output
Video Analytics
Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Heatmap; Loitering; Running; Parking; People Counting; Crowed Detection; Safety Helmet Detection; On Duty Detection; Video Abnormal; Audio Abnormal
Auto-Tracking
Yes
Face Mode
Face Capture
Face Capture Performance
60; 19; ≤100m; Detect up to 32 faces at the same scene; Capture up to 16 faces at the same scene; Capture rate ≥99%(continuous scene with 10 people or less); Gender 85%,age (±5) 85%,mask 90%,glasses 85%,beard 80% (Less than 10 people in view)
